DOWNLOAD DATA SHEET
Specification:
- 264 High Profile
- C/CS mount, Auto Iris
- Color: White
- Dimension :105(L) x85(W) x70(H)mm
- Weight:0.5KG
- Motion detection
Parameter:
| Model | JR-IP320-2.2M |
| Image Sensor | HI3516C+IMX322 |
| TV System | PAL/NTSC |
| Image Resolution | 1920*1080 |
| Horizontal Resolution | 2.2MP |
| SYNC. | Internal |
| Video Out | 1.0Vp-p Composite Signal (75ohm) |
| Minimum illuminator | 0 .001Lux (Infrared Light Open) |
| Gama adjust | 0.45 |
| Infrared Sensitivity | Support |
| S/N Ratio | 58dB(min)(AGC closed) |
| Lens | C/CS mount, Auto Iris |
| Leds | 24pcsΦ10mm30° LED+24pcsΦ10mm45°LED |
| IR Distance | 30 m |
| DNR | Yes |
| AWB | AUTO |
| AGC | AUTO |
| BLC | ON/OFF |
| Day/Night | Yes |
| OSD | / |
| Compression Technology | H.264 High Profile |
| Max Coding Rate | 128-8192kbps |
| Encoding Type | CBR or VBR |
| R/N Ratio | More than 50DB |
| Image intensification | Brightness, Contrast, Saturation, HU Adjustable |
| Subtitle Input | Support Channels name, Date & time |
| Video Orientation | Left & Right Mirror, Up & down Flip |
| Audio input | Optional |
| Audio Format | G.711/G.726 |
| Alarm | Motion Detection(Sensitivity adjustable) |
| Alert Processing | Control Center monitoring, go to preset point, Email send MSG, Log Record, Video & PIC save on PC |
| Network Port | Ethernet(10M/100M Base-T),RJ45 |
| Safety | IP Address Filtering, User rank protect, User login log |
| Software management | CMS, Onvif support different platform software |
| Video Protocol | TCP,UDP,IP,HTTP,FTP,SMTP,DHCP,DNS,ARP,ICMP,POP3,NTP,R TP, and RTSP, Onvif2.0 |
| Network Port | Support DDNS, P2P(NAT),software remote access |
| Power Input | DC12V±1V |
| Operation Temperature | Temperature -10℃～+75℃,Humidity less than 85%RH |
| OSD Language | Chinese English |
| Dimension | 105(L) x85(W) x70(H)mm |
| Weight | 0.50KG |
